Butterfly Valves

In these robust valves, the internal component used to shut off the flow is a segment of a sphere.This allows frequent operation with very low torque, no fluid retention areas and therefore excellent mechanical performance.

Полное описание продукта

In these robust valves, the internal component used to shut off the flow is a segment of a sphere.

This allows frequent operation with very low torque, no fluid retention areas and therefore excellent mechanical performance.

Features/Benefits:

- Compact & Abrasion-resistant

• Excellent with abrasive fluids (including solid particles)
• Fluid flow direction marked for greater safety (uni-directional)
• Smooth operation
• Can be easily adapted for use with auxiliary actuators
• More compact than a ball valve with equivalent nominal diameter
• Simple and efficient design for a long service life

Markets:

• Coating / Ink / Paint
• Machine Tools
• Plumbing
• Rubber & Tire Processing
• Oil & Gas

Applications:

• Allow/Stop Abrasive Fluids Circulation Including Solid Particles
• Suitable for Applications Requiring Frequent Operations

Technologies:

• Shut-off valve
• Butterfly valve
• Industrial valve
• Water pressure reducing valve
• Pressure regulating valve

Technical Characteristics:

• Fluids: Compressed air, industrial gases, water, cutting oils, hydraulics oils, fuel oil, fuel, etc.
• Materials: zamak, black epoxy paint, nickel-plated shot-blasted brass, NBR, stainless steel, brass, silicone free
• Pressure: 0 to 16 bar
• Temperature: -20°C to +80°C

Regulations:

• DI: 97/23/EC (module PED A - diameters greater than 25 mm)
• DI: 2006/42/EC (Machinery Directive)
• DI: 2002/95/EC (RoHS)
• RG: 1907/2006 (REACH)

Product Types:

• 2/2 Butterfly Shut-Off Valve, Female BSPP Thread

Характеристики

Материал уплотнения шарика:	NBR
Материал корпуса:	NICKEL PLATED BRASS
Тип ручки:	ZAMAK
Материал уплотнительного кольца:	NBR
Материал штока:	BRASS
Материал уплотнения штока:	NBR
Диаметр:	Nominal: 6 to 18 mm
Максимальное рабочее давление:	16 bar
Минимальная рабочая температура:	-20 °C
Максимальная рабочая температура:	80 °C
Количество в одной коробке:	1 to 10
Вес:	0,102 to 0,412 kg
Применение:	Painting & Printing, Machine Tools, Pneumatics, Powder Conveyance, Plumbing, Rubber Industry, Petrochemical
Рабочая среда:	Compressed air, industrial gases, water, cutting oils, hydraulic oils, fuel oil, fuel, etc.
Соблюдены требования технических условий:	REACH, ROHS
Форма:	Butterfly valve female
Тип продукта:	Butterfly Valves
Размер резьбы соединения 1:	BSPP
