Inline Shuttle Valves ASH-06-2

Parker's ball type inline shuttle valves are plumbed external from manifolds and line bodies and are available in two flow size options of 11 lpm (3 gpm) or 22 lpm (6 gpm), and pressures up to 207 bar (3000 psi).

Parker's ball type inline shuttle valves can handle flows up to 22 lpm (6 gpm) and 207 bar (3000 psi) in a body that is meant to plumbed external of manifolds or line bodies within a hydraulic circuit. These valves of two porting options available: either a ¼” JIC thread or an SAE -6 port. These reliable ball type inline shuttle valves function similar to the cartridge style valves, but give the advantage of being able to mount wherever is convenient on the mobile or industrial equipment.

Markets:
• Aerial
• Construction Equipment
• Forestry Equipment
• Material Handling Equipment
• Miscellaneous Industrial
• Miscellaneous Manufacturing
• Miscellaneous Mobile

Features/Benefits:
• Compact in size
• In-line mounting
• Easily adaptable to various applications
• All external parts zinc plated

Applications:
• Load Sensing

Additional Technical Insight:
This is a compact line mounted ball type valve with low leakage and a large flow range.
